AM740R Roll Crusher

AM740R Roll Crusher

Roll crusher smash materials by two pairs of opposite moving roller. Materials enter to crushing chamber from feed, By friction of the opposite moving roller, materials will be crushed roughly, the first time crushed material will enter below to the chamber of another two moving roller, and to crush again. the smallest cleft of the two rollers is the width of discharge gate, which is equal to the largest feed size of the crushed materials. If material is too hard to crush, cleft between two rollers will be increase, to let hard material discharge, by the function of spring, rollers will be recovered to the normal cleft, to protect machine.

Roll crusher fits to crush medium, hard, and fragility materials and to make sample preparation into comminution.

Performance Advantages

A.Frame of the machine can be disassembly, that is convenient to clean.

B.Two pairs of roller to smash automatically, to make sample preparation more efficiency.

C.Assemble wear-resistant lining, which with wear-resistant material, to increase the value or the life of the equipment.

D.Width cleft between the two rollers can adjust to discharging granularity.

E.Scraper plate can work automatically, to avoid wet and stick materials adhere rollers.

F.Rotary switch rotary, easy to operation.

G.Dual-motors drive, with powerful energy, and fast rotary speed, can be make sample preparation with hard materials, and with high productivity.

H.Can connect to autotransporters to make sample preparation continually.

I.Rollers can adjust to rotary direction, to avoid sticking materials.

J.The surrounding plates can be disassembled that is convenient to the cleaning of internal crushing chamber.

K.The roller is equipped with spring device to reduce material stick and protect the transmission system.

L.The adhesive sample can be grinded.

Technical Information
